ASTM A312 Stainless Steel Pipe

ASTM A312 Stainless Steel Pipe

Description:

Type: Seamless Cold Drawn Tubes, Hot Finished Seamless Pipes, Welded Pipes

Specification: Seamless(OD: 10.3mm to 610mm), Welded(OD: 10.3mm to 914mm) Length: 0-12m.

Standard: ASTM A312 ASME SA312

Grades: TP304, TP304L, TP304H, TP321H, TP321, TP316, TP316L,

Thickness: SCH 5/5S, 10/10S, 20/20S, 40/40S, 80/80S, 120/120S, 160/160S

Finish: No.1 Pickled Finish, No.4 finish, BA Finish, Electropolished Seamless Pipes

What is the ASTM A312 Steel Pipe?

Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes,

STM A312 pipe is the general use stainless steel pipe applied in different industries. It covers diameters from 1/8” to 30” and thickness from SCH 10S to SCH 80S. Common use material grades are  TP304, TP304L, TP304H, TP321H, TP321, TP316, TP316L.

The standard specifications include seamless, straight seam welded and heavily cold welded austenitic stainless steel tubing for high temperature and general corrosive service. There are several grades in this standard, and each steel grade shall confirm to the required chemical composition of C, Mn, P, S, Si, Cr and Cr, Ni, Mo, etc. All the pipes shall be furnished in the heat-treated condition in accordance with the required heat treating temperature and cooling/testing requirements. And also need to comply to the required tensile strength and yield strength.

Chemical Requirements for ASTM A312 Pipe
