ASTM A789 Stainless Steel Pipe
Product description: ASTM A789 Stainless Steel Pipe
ASTM A789 Stainless Steel Pipe
Description:
Types: Stainless steel welded pipe, stainless steel seamless pipe
Specification: OD: 6.0-630mm. WT: 0.5-45mm. L.: up to 12m or customized length.
Standard: ASTM A789, ASME SA A789
Grade: S32304, S31803, S32205, S32750, S31260, S32550, S32760, S32707. etc.
Ends: Plain End, Beveled End, Threaded
Packaging: Bundle, plywood case, customized or standard export package.
What is the ASTM A789 Steel Pipe?
Standard specification for seamless and welded ferritic austenitic stainless steel pipe
Material Grade:UNS 31803,S32205,S32101,S32304,S32750,S32760,1.4462,1.4410etc.
UNS | C | Mn | P | S | Si | Ni | Cr | Mo | N | Cu | Other |
S31200 | 0.030 | 2.00 | 0.045 | 0.030 | 1.00 | 5.5–6.5 | 24.0–26.0 | 1.20–2.00 | 0.14–0.20 | . . . | . . . |
S31260 | 0.030 | 1.00 | 0.030 | 0.030 | 0.75 | 5.5–7.5 | 24.0–26.0 | 2.5–3.5 | 0.10–0.30 | 0.20–0.80 | W 0.10–0.50 |
S31500 | 0.030 | 1.20–2.00 | 0.030 | 0.030 | 1.40–2.00 | 4.3–5.2 | 18.0–19.0 | 2.50–3.00 | 0.05–0.1 | . . . | . . . |
S31803 | 0.030 | 2.00 | 0.030 | 0.020 | 1.00 | 4.5–6.5 | 21.0–23.0 | 2.5–3.5 | 0.08–0.20 | . . . | . . . |
S32001 | 0.030 | 4.00–6.00 | 0.040 | 0.030 | 1.00 | 1.0–3.0 | 19.5–21.5 | 0.60 | 0.05–0.17 | 1.00 | . . . |
S32003 | 0.030 | 2.00 | 0.030 | 0.020 | 1.00 | 3.0-4.0 | 19.5-22.5 | 1.50-2.00 | 0.14-0.20 | . . . | . . . |
S32101 | 0.040 | 4.0-6.0 | 0.040 | 0.030 | 1.00 | 1.35-1.70 | 21.0-22.0 | 0.10-0.80 | 0.20-0.25 | 0.10-0.80 | . . . |
S32202 | 0.030 | 2.00 | 0.040 | 0.010 | 1.00 | 1.00–2.80 | 21.5–24.0 | 0.45 | 0.18–0.26 | . . . | . . . |
S32205 | 0.030 | 2.00 | 0.030 | 0.020 | 1.00 | 4.5–6.5 | 22.0–23.0 | 3.0–3.5 | 0.14–0.20 | . . . | . . . |
S32304 | 0.030 | 2.50 | 0.040 | 0.040 | 1.00 | 3.0–5.5 | 21.5–24.5 | 0.05–0.60 | 0.05–0.20 | 0.05–0.60 | . . . |
S32506 | 0.030 | 1.00 | 0.040 | 0.015 | 0.90 | 5.5–7.2 | 24.0–26.0 | 3.0–3.5 | 0.08–0.20 | . . . | W 0.05–0.30 |
S32520 | 0.030 | 1.50 | 0.035 | 0.020 | 0.80 | 5.5–8.0 | 23.0–25.0 | 3.–5. | 0.20–0.35 | 0.50–3.00 | . . . |
S32550 | 0.04 | 1.50 | 0.040 | 0.030 | 1.00 | 4.5–6.5 | 24.0–27.0 | 2.9–3.9 | 0.10–0.25 | 1.50–2.50 | . . . |
S32707 | 0.030 | 1.50 | 0.035 | 0.010 | 0.50 | 5.5–9.5 | 26.0–29.0 | 4.0–5.0 | 0.30–0.50 | 1.0 max | Co 0.5–2.0 |
S32750C | 0.030 | 1.20 |
